Electric Vacuum Conveyor

The electric vacuum conveyor is one kind of powder free transfer feeding conveyor, it is working on the vacuum pump which driven by electric motor. It mainly applied for the wheat flour, sugar, plastic granules feeding for the packing machine, mixer machine etc.

Model: ZKS-1, ZKS-2, ZKS-3, ZKS-4, ZKS-5, ZKS-6, ZKS 10-6, ZKS 20-5

Material: Stainless Steel S304, S316

Conveying distance: Customized

Description



  • Introduction

The electric vacuum conveyor is working on the vacuum pump which driven by electric motor, it has lower vacuum energy consumption, no energy conversion, high efficiency and wide application. When vacuum pump work to suction the air, the inlet of the suction nozzle and the whole system are in a certain vacuum state. The powder particles are sucked into the nozzle along with the outside air to form a air stream, which passes through the suction pipe and reaches the hopper. Air and material separation. The separated material enters the receiving equipment. The feeding and discharging are completed by continuously opening and closing the pneumatic three-way valve, and the opening and closing of the pneumatic three-way valve is controlled by the control center.

  • Advantage

GMP Standard Qualified

High efficiency and safe conveying

Convenient Installation and simple operation

Dust-free working space

Low energy consumption and cost saving

  • Parameters
Model Capacity (kg/h) Hopper volume(L) Air pressure(Mpa) Motor power(kW)
ZKS-1 200-400 8 0.4-0.6 1.5
ZKS-2 400-600 8 0.4-0.6 2.2
ZKS-3 600-1200 12 0.4-0.6 3
ZKS-4 1200-2500 42 0.4-0.6 5.5
ZKS-6 1500-3200 42 0.4-0.6 5.5
ZKS-7 2500-6000 60 0.4-0.6 7.5
ZKS-10-6 About 6000(when transporting distance within 10m) 120 0.4-0.6 7.5(Roots Fan)
ZKS-20-5 About 5000(when transporting distance within 10m) 280 0.4-0.6 11(Roots Fan)
